SKU: ES20103

Sprocket Caterpillar 320 322 323 324 326 21T 16H 456ID

RRP $330.00 SAVE $85.00 (26%)
$245.00

In Stock


Description

Compatible with the following equipment:

CATERPILLAR

315C ANF-1-UP    318BN 7KZ -1-UP    318BN AEJ -1-UP    318C ADC-1-UP
318C AEJ-1-UP    318C BTG-1-UP    318C FAA-1-UP    319E KGL -1-UP
320 2DL -1-UP    320 3RK -1-UP    320 3XM -1-UP    320 7WK -1-UP
320 8LK -1-UP    320B 5BR -1-UP    320BL 6CR -1-UP    320BL LN 3YZ -1-UP
320BLL 6LS -1-UP    320BLL 9JS -1-UP    320C AKH -1-UP    320C AMC -1-UP
320C APA -1-UP    320C BCB -1-UP    320CL ALF -1-UP    320CL BDB -1-UP
320CL BGB -1-UP    320D A6F-1-UP    320D AZR-1-UP    320D BWZ-1-UP
320D BZP-1-UP    320D CXY-1-UP    320D DFT-1-UP    320D EBT-1-UP
320D FAL-1-UP    320D GKS-1-UP    320D JFGZ-1-UP    320D JFZ-1-UP
320D JPD-1-UP    320D KLM-1-UP    320D MCH-1-UP    320D MZD-1-UP
320D SNS-1-UP    320DL A8F-1-UP    320DL A9F-1-UP    320DL BWP-1-UP
320DL DHK-1-UP    320DL FNA-1-UP    320DL FXF-1-UP    320DL GDP-1-UP
320DL KGF-1-UP    320DL KZF-1-UP    320DL MDE-1-UP    320DL MGG-1-UP
320DL PDS-1-UP    320DL PHX-1-UP    320DL SPN-1-UP    320DL TDH-1-UP
320DL WJN-1-UP    320L 1KL -1-UP    320L 1TL -1-UP    320L 3XK -1-UP
320L 4BK -1-UP    320L 9KK -1-UP    320N 1XM -1-UP    320N 9WG -1-UP
321C DAX-1-UP    321C KBB-1-UP    321C KCR-1-UP    321C MCF-1-UP
321C LC     322 7WL -1-UP    322B 3NR -1-UP    322BL 1YS -1-UP
322BL 2ES -1-UP    322BL 8NR -1-UP    322BLN 1ZS -1-UP    322CL
322L 7WL -1-UP    322L 8CL -1-UP    322L 9RL-1-UP    322LN 4RM -1-UP
322N 9JL -1-UP    323DL BYM-1-UP    323DL JLG-1-UP    323DL NDE-1-UP
323DL PBM-1-UP    323DL SDC-1-UP    323DLN CYD-1-UP    323DLN RAC-1-UP
324D T2D-1-UP    324DL DFP-1-UP    324DL JJG-1-UP    324DL LAB-1-UP
324DL SYM-1-UP    324DLN BYE-1-UP    324DLN EJC-1-UP

CROSS REFERENCE (Original codes):
BERCO    CR5602
BERCO    CR6998
CATERPILLAR    8E9805
ITM    R7820000M01
KOMATSU ALL MAKES    ZZYS0031
VPI    VCR5602V

Specifications

SKU ES20103
Shipping Weight 41.0000kg
Shipping Width 0.600m
Shipping Height 0.400m
Shipping Length 0.800m
Shipping Cubic 0.192000000m3
