SKU: P9S120X1020TNG

Excavator Pin 120x1020 mm IDxTL Boom Base Pin (P2) PC400-7/8 PC450LC-7/8 PC490LC-11 PN 208-70-71590

$1,950.00



Description

Compatible with the following equipment:

KOMATSU

  • PC400-7 PC400-7 SERIAL NUMBERS : J20001-UP
  • PC400-7-M1 PC400-7E0 PC400-8 PC400LC-7 PC400LC-7-M1 PC400LC-7E0 PC400LC-7L PC400LC-8 PC400LCSE-8R  PC400-8R PC400LC-8R
  • PC450-7 PC450-7-M1 PC450-7E0 PC450-7K PC450-7K-E0 PC450-8 PC450LC-7 PC450LC-7-M1 PC450LC-7E0
  • PC450LC-7K PC450LC-7K-E0 PC450LC-8 PC450LC-8K HIGH REACH DEMOLITION
  • PC450LCHD-8 PC460LC-8 PC490LC-10
  • PC450-8R PC450LC-8R PC490-10 PC490LC-11 PC550LC-8







Part Number : 208-70-71590  2087071590  208-70-71591  2087071591

Pin-and-Bush-Location-Diagram



Lucas Parts stock a range of pins and bushes to fit mini excavators from 0.75 ton up to 40 ton.


Our pins are induction hardened for maximum wear resistance. Made from high carbon steel equal to 40Cr or 45 # steel. Quenching depth from 1.5-2.8mm and hardness is HRC 52-55.

Specifications

45# type steel is the high quality carbon structural steel, carbon content is 0.42-0.50%, with 610 Mpa tensile strength , and yield point is 428 Mpa; it is widely used in machinery parts.









SKU P9S120X1020TNG
Shipping Weight 120.0000kg
Shipping Width 0.600m
Shipping Height 0.300m
Shipping Length 1.200m
Shipping Cubic 0.216000000m3
Unit Of Measure ea
